pH-20N

* Backlight Custom LCD
* Short Response time
* Bi-directional RS232C



* Waterproof(IP66) housing, Backlit custom LCD display

* Fast, accurate and easy-to-use, RS 232C communication

* Simultaneous display of pH, temp, and current time

* Auto(Manual) calibration with choice of buffer(3points)

* Automatic compensation for Temp, Self-diagnostics

* Low Battery Alarm, Rechargeable Battery

* Data-log up to 100 Points, Auto power-off

* Certificate CE mark, GD mark


pH

  Range

 -2.00 to 19.99

  Resolution

0.01

  Relative Accuracy

 ±0.02

  Auto-Buffer-Recognition

 pH : 4.00, 7.00, 10.00

 Millivolts

  Range

 ±1999.9mV

  Resolution

 ±0.1mV

  Relative Accuracy

 ±0.1mV

 Temperature

  Range

 -10 to 100℃

  Resolution

0.1℃

  Relative Accuracy

 ±0.4℃

 Temperature Compensation

 Auto

 Calibration

 Auto (3 Points) / Manual (3 Points)

 Datalog

 100 Points

 Print Capability

 Yes

 Display

 Backlight LCD

 Inputs

 BNC, 8PIN(ATC), 7.5V Adaptor

 Outputs

 RS232C (Computer / Printer)

Power

 Rechargeable Battery/ DC Power Adaptor

 Certification

 CE, GD mark

 Dimension

 220(L) x 80(W) x 40(H), Weight 0.45kg

 Waterproof

 IP66


(1) Standard
   - Combination pH Electrode / ATC Probe
   - Buffer Solution (pH 4.00, 7.00, 10.00) 90ml
   - Rechargeable Battery /DC Adaptor
   - Instruction Manual


(2) Option
   - Buffer Solutions (pH 4.00, 7.00, 10.00) 475ml
   - Electrode Storage Solution
   - Carrying Case
   - Electrode Filling Solution
   - RS232C Interface Cable
   - Exterior Thermal Printer
