* Displays pH and Temp at once* Hight Limit / Low Limit* RS232C Connecting with PC
* Microprocessor based on single chip* Programmable dialogue-Menu for easy operation* Convenient LCD, LED display (Measure, Calibrate, Data display)* User password function for protection* Easy to stop of Relax by "control-cut" function.* Low maintenance cost, High/Low alarm setting* Standard serial communication by connectiong with PC(RS232C)* Sewage & Waste water disposal plant, Filtration, River
pH
ORP
Range
0.00 ~ 14.00
¡¾1999.9mV
Resolution
0.01 / 0.1
0.1mV
Relative Accuracy
¡¾0.01
¡¾0.01mV
Calibration
3 Point
-
Temperature
-5¡É ~ 100¡É (Pt 100 Sensor )
Respond Time
Less than 10 seconds
Control Type
ON/OFF Control (Proportional Control : option)
Outputs
-Analog output: 4¢¦20mA -Relay output : Two SPDT Relays
-Alarm : One SPDT Relay -Serial output : RS232(RS485:option)
Display
Dual display of pH and Temperature
Enclosure
-Full-protection insulated -Waterproof Rating : IP65
-Material : Polystyrene -Mounting Method : Wall Mount Type
Power/Dimension
AC 110V /220V (50/60Hz) / 210(W) X 185(H) X 84(D)mm
Standard Accessories
-Instruction Manual -AC Power Adaptor
Optional Accessories
-pH Electrode –ATC Probe –pH Buffer Solution
-Holder –Extra Cable(10~50m) –Relay Box
-Bracket –Washing System (Air, Water-Jet, Ultrasonic)
(1) Standard - AC / DC Adaptor - Buffer Solution (pH 4.00, 7.00, 10.00)125ml - Instruction Manual(2) Option - Combination pH Electrode/ATC Probe - Electrode Storage Solution - Electrode Filling Solution - Buffer Solution (pH 4.00, 7.00, 10.00)475ml - Holder (P.P, PVC, STS Etc.) - Bracket ('L' Rack Mount, Screw Mount Etc.) - Extra Cable(10~50m) - Washing System (Air, Water-Jet, Ultrasonic) - Relay Box
¡ã Holder & Bracket ¡ã Relay Box ¡ã Cleaning System
