pH Range |
Temperature Range |
Diameter |
Length |
Internal Reference Element |
|
0-13 |
0 to 80℃ |
12mm |
115mm |
Ag/AgCl Sealed/ATC |  Application : Water, Education, Field, Sea water, Swimming pools
Feature : Epoxy Body, General, PT100(온도복합)
|
5733528AS |
|
|
|
|
|
|
|
|
pH Range |
Temperature Range |
Diameter |
Length |
Internal Reference Element |
|
0-14 |
-5 to 80℃ |
12mm |
115mm |
Ag/AgCl Sealed/ATC | Application : Water, Education, Field Use, Sea Water, Swimming Pools
Reference : Solid Polymer Reference, Double Junction, Sealed
Feature : Epoxy Body, PT100(온도복합),
|
|
V-700B |
|
|
|
|
|
|
|
| Model NO. | 201T Series | | pH Range | 0~14 | | Temperature Range | 0~80 ℃, 온도 복합 | | Electrolyte | Gel KCl | | Body material | PC(Polycarbonate) | | Junction | Single Ceramic | | Reference | Ag/AgCl | | Dimension | Φ12 x 160 mm | | Electrical connection | T-F:BRCA / T-Q:B4pin, 1m cable | | 특징 및 응용 | -일반적인 pH측정에 사용 | | | -적용모델 201T-F : PH850 / PH8500 / PC8500 | | | -적용모델 201T-Q : AM70 |
|
|
201T Series |
|
|
|
|
|
|
|
|
pH Range |
Temperature Range |
Diameter |
Length |
Pressure |
Cable Length |
|
0-13 |
-5 to 130℃ |
12mm |
120mm |
≤ 10bar |
2m | Application : 고온, 고압용 pH 전극
Reference : Solid Polymer Reference, Double Junction, Sealed
Feature : Glass Body, PT100(온도복합)
|
|
BP600-010BRCA-B120 |
|
|
|
|
|
|
|
|
pH Range |
Temperature Range |
Diameter |
Length |
Pressure |
Cable Length |
|
0-14 |
0 to 100℃ |
12mm |
120mm |
100psi |
별도구매 |
Application : 고온, 고압용 pH 전극(Cable 분리형), 13.5 Threaded, DL4pin
Reference : Solid Polymer Reference, sealed, Double Junction
Feature : Glass Body, PT100(온도복합), 케이블 별도구매
|
|
HABP635KN-V12 |
|
|
|
|
|
|
|
|
pH Range |
Temperature Range |
Diameter |
Length |
Internal Reference Element |
|
0-13 |
0 to 100℃ |
12mm |
110mm |
Ag/AgCl Sealed | Application : Water, Education, Micro Sample
Feature : Glass Body, Troide PT100(온도복합)
|
|
577V593A2(5773593A2) |
|
|
|
|
|
|
|
